Phoenix P1000

Phoenix P1000 - Bilde 2

Phoenix P1000

Pumpehus

Membraner

Kuler

Sete

Beskrivelse

Fluid connections: 3” BSP – DN 80
Air connection: 3/4” BSP
Max flow-rate: 1050 lt/min
Max air pressure: 8 bar
Max delivery head: 80 m
Max Suction Lift Dry: 5 m
Max Suction Lift Wet: 9,8 m
Max Solid passing: 12 mm
Noise level: 82 dB
Max Viscosity: 55.000 cps
Displacement per stroke: 9750 CC~

Tilleggsinformasjon

Tilleggsinformasjon

Pumpehus	ALU, PP, SS
Membraner	HYTREL, SANTOPRENE, SANTOPRENE + PTFE
Kuler	EPDM, NBR, PTFE
Sete	ALU, INOX, PP

Brosjyre
